Description
The MGE-ASQ2 Trolley Automated Washer Disinfector is designed to efficiently clean, disinfect, and dry reusable medical instruments and equipment such as surgical tools, glassware, anesthesia instruments, and plastic items. It plays a crucial role in infection control within hospitals by ensuring high-quality disinfection, which directly impacts the performance of central sterile supply departments (CSSD).
Key Features:
- High Efficiency: Speeds up the cleaning and disinfection process, saving time and effort while ensuring reliable sterilization.
- Multi-Functional Use: Suitable for various items, including surgical instruments, glassware, anesthesia equipment, and plastic products.
- Safe and Convenient: Easy to operate with built-in safety features to ensure smooth and secure disinfection procedures.
- Optimized for Infection Control: Ensures high-quality cleaning and sterilization, reducing the risk of hospital-acquired infections.
Product Paramenter
| Specification | Details |
|---|---|
| Model | MGE-ASQ2 |
| Place of Origin | China |
| Language | English/Spanish |
| Inner Cabin Material | 304 Stainless Steel |
| Drying Temperature | 90°C (194°F) for 20 minutes |
| Disinfection Temperature | 93°C (199.4°F) |
| Number of Cleaning Racks | 4 |
| Number of Baskets | 12 |
| Control System | Siemens PLC |
| Equipment Category | Fixed |
| Outer Box Size (L*W*H) | 1270*1000*2020mm (50.0*39.4*79.5 in) |
| Cleaning Cabin Size (L*W*H) | 693*828*935mm (27.3*32.6*36.8 in) |
| Total Volume | 536L (18.9 cu ft) |
| Power Supply | 3N~220V, 50Hz |
| Power | 30kVA |
| Ambient Temperature | 5°C~40°C (41°F~104°F) |
| Relative Humidity | ≤80% |
| Atmospheric Pressure Range | 70kPa~106kPa |
| Water Supply Pressure | 0.2MPa~0.5MPa |
| Inlet Water Temperature | 5°C~40°C (41°F~104°F) |
| Working Cabin Material | 304 Stainless Steel |
| Load Frame Trolley Material | 304 Stainless Steel |
| Working Noise | ≤75dB(A) |
| Appropriate Types | Radioactivity, Pollution, Large Quantities, High Cleanliness |
| Operating Mode | Custom Mode: Each process request time and working temperature parameters can be customized. Standard Mode: 6 preset modes |
| Functional Accessories | Thermal Printer, 7″ LCD Touch Screen, USB Data Port, 4 Movable Casters, 4 Fixed Tripods |
